J-SERIES
Description
Commercial Grade LED tape utilizing 90+ CRI diodes. With a variety of outputs and CCT options, this product is versatile enough to be used in a wide range of linear accent applications.
Specifications
Downloads
Specifications
- Voltage: 24V
- CCT:
- Static White: 27K, 30K, 35K, 40K, 50K
- Static Color: Red, Green, Blue, Amber, Violet
- Lumens:
- Static White: 200, 400, 600, 800
- Beam spread 120°
- CRI:
- Static White :90+
- Static Color: N/A
- Max Run:
- Static White: 40′ (200lm), 30′ (400lm), 19′ (600lm), 14′ (800lm)
- Static Color Max Run: 20′
- Cut marks: 50mm (1.97″)
- IP Rating: IP20(dry), IP65 (wet)
- Operating Temperature:
- White Static: -40°F (-40°C) to 131°F (55°C)
- Static Color: -22°F (-30°C) to 122°F (50°C)
- Lumen Maintenance: 50,000
- UL Listed
- Dimension:
- Static White
- Indoor: 10mm (0.39”) x 2mm (0.08”)
- Outdoor: 12.50mm (0.49”) x 4mm (0.16”)
- Static Color
- Indoor: 10mm (0.39”) x 2mm (0.08”)
- Outdoor: 12.50mm (0.49”) x 4mm (0.16”)
- Static White
- Binning Tolerance:
- Static White: Single Binning
- Static Color: N/A
